LED Floodlight
Product Code: 680
Description
Metro Series Floodlight in 2 sizes features IP66 construction and high performance LED optics to provide high efficiency lighting. Suitable for exterior and industrial installations.
Construction
Construction: Die-cast aluminium with Galvanised steel U Bracket. IP66. IK08 as standard. Driver and LED Modules are accessible for maintenance or replacement.
Lens: Tempered glass as standard.
Installation: Via Galvanised steel U Bracket supplied.
Finish: Grey RAL 9006 as standard. Other RAL colours on request.
Product Compliance: EN 60598, CE.
Options
Options: Dimming, DALI, Photocell, various optics available.
Electrical
LED: Available 19w to 170w LED (see ordering codes). 4000K CRI 70 as standard. 3000K or 5000K and other CRI on request. Forward Throw B optic as standard. See ordering codes for more details.
LED Lifetime: L90 B10 >100,000 hours (at 25° C).
Driver: 220-240V AC 50/60 Hz. 700mA as Standard. 350mA, 500mA, 1050mA or custom setting on request.
Mains Surge Protection: 10kV device included as standard.
Temperature: -30° C to +40° C
Downloads
Product Leaflet: Download Product Leaflet
