Local Authority Streetlight
Product Code: 386
Description
Modern functional LED luminaire, available in 2 sizes. Ideal for roadway applications.
Construction
Construction: Die-cast aluminium IP66. Driver and LED Modules are accessible for maintenance or replacement.
Lens: Tempered Glass Lens.
Size 1: IK10
Size 2: IK08 as standard (IK10 Available on request)
Installation: Luminaire supplied with 76mm mastfitter for post-top mounting as standard. Luminaire available with 60mm mastfitter for outreach/side entry installation on request.
Tiltable:
Size 1: Post-Top: +25°, -5°
Side Entry: +5°, -25°.
Size 2: Post-Top: +10°, -10°
Side Entry: +10°, -10°.
Finish: Grey RAL 9006 as standard. Other RAL colours on request.
Manufactured: EU.
Product Compliance: EN 60598, CE.
Options
Dimming, DALI, Photocell, various optics available. Heat sink cover available on size 1, wattage needs to be reduced appropriately; Special Version for Marine areas.
Electrical
LED: : Available in 10w to 136w LED. CRI 70 on 4000K (standard). 3000K , 2700K, 2200K or Amber on request. Asymmetric street optic A10 as standard. See ordering
codes for more details.
LED Lifetime: L80 B10 >100,000 hours (at 25°C).
Driver: 220-240V 50/60Hz. 700mA as Standard. 350mA, 500mA or 1050mA on request.
Lifetime (<10% failures): 100,000 hrs.
Mains Surge Protection: 10kV device included as standard.
Downloads
Product Leaflet: Download Product Leaflet
Photometrics: see Lighting Design note.
– 5TCA11GLB – 28w LED -Street Optic
– 5TCA11GLB-S – 28w LED -Street Optic – S
– 5TCB15GLA – 136w LED – Street Optic
– 5TCB15GLB – 136w LED – Forward Throw
Several other Optics available.
ALTERNATIVES:
Download Product Leaflet no. 610 – Durostar Streetlight
Competitively priced, but designed for 50,000 hour life (so not suitable for Local Authority Road Lighting)
Download Product Leaflet no. 675 – Metro Streetlight
